Yousef Metals stands out as a reliable manufacturer and supplier of top-notch Monel 400 Flanges in Doha, Qatar. They cater to various industries, including oil & gas, marine, petrochemical, and power. Known for their impressive corrosion resistance, especially in challenging environments like seawater, acids, and alkaline solutions, these flanges are crafted to meet ASTM, ASME, and ANSI standards. This ensures that they provide secure, leak-proof connections in critical piping systems. With state-of-the-art manufacturing facilities, rigorous quality control, competitive pricing, and prompt delivery, Yousef Metals delivers dependable flange solutions for demanding industrial needs throughout Qatar and the Middle East.
Monel 400 Flanges are composed of a nickel-copper alloy, featuring around 63–70% nickel and 28–34% copper, along with trace amounts of iron and manganese. This unique blend grants them exceptional resistance to corrosion, pitting, and stress corrosion cracking. The alloy also boasts good tensile and yield strength, remarkable toughness, and reliable performance across a wide temperature range. These mechanical properties enable Monel 400 flanges to endure high pressure, chemical exposure, and tough environmental conditions.
| Specification | ASTM B564 / ASME SB564 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating ANSI | Class 150 LBS, 300 LBS, 400 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203; UNI2276 |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Blind Flanges from Yousef Metals ensures unmatched quality and long-lasting performance. These Flanges are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise. Yousef Metals provides reliable and high-performance Monel 400 Flanges tailored to meet your specific operational and project requirements.
Yousef Metals, one of the leading suppliers of Monel 400 Flanges in Doha, Qatar, offers a wide selection of high-quality flanges suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Yousef Metals has established itself as a trusted name for premium stainless steel products across the Qatar.
Yes, we provide Monel 400 Flanges to match your exact project requirements. At Yousef Metals, our team is dedicated to delivering tailored flanges solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@yousefmetals.com.
These flanges find extensive use in marine engineering, offshore oil and gas platforms, chemical processing plants, and power generation systems. They are particularly suited for applications involving seawater, brine, hydrofluoric acid, and alkaline solutions. In Qatar’s energy and marine sectors, Monel 400 Flanges play a crucial role in supporting pipelines, heat exchangers, pressure vessels, and fluid transfer systems. Their outstanding corrosion resistance, durability, and long service life make them a trusted choice for demanding industrial applications.
