Inconel 617 forged fittings are top-notch piping components crafted for the toughest high-temperature and high-pressure settings. Made from a unique nickel–chromium–cobalt–molybdenum alloy, these fittings deliver outstanding strength, resistance to oxidation, and impressive thermal stability over time. The forged design boosts their structural integrity, ensuring they perform reliably even under intense mechanical and thermal stress. Inconel 617 is renowned for its remarkable creep resistance and ability to withstand carburization at elevated temperatures. These fittings meet international standards and are perfect for critical industrial applications that demand exceptional heat and corrosion resistance.
Inconel 617 is mainly made up of nickel, with notable amounts of chromium, cobalt, and molybdenum added in. This sophisticated alloy mix offers fantastic resistance to oxidation, carburization, and high-temperature corrosion. The forged fittings made from Inconel 617 showcase high tensile and yield strength, impressive toughness, and exceptional creep and rupture resistance when exposed to high temperatures. They maintain their mechanical stability even under prolonged heat exposure, thermal cycling, and high-pressure conditions.
| Standards | ASTM, ASME |
| Designation | B564, SB564 |
| Dimension Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Grade | Inconel 600 Forged Fittings. |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Types of Forged Fittings | Elbow, Tee, Union, Cross, Swage Nipples, Coupling, CAP, Plug, Bush. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 617 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 617 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Inconel 617 Forged Fittings from Yousef Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Yousef Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Yousef Metals, one of the leading suppliers of Inconel 617 Forged Fittings in Doha, Qatar, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Yousef Metals has established itself as a trusted name for premium stainless steel products across the Qatar.
Yes, we provide custom sizes of Inconel 617 Forged Fittings to match your exact project requirements. At Yousef Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@yousefmetals.com.
Inconel 601 Forged Fittings are widely used across industries requiring exceptional heat and corrosion resistance. They are commonly applied in furnace components, heat-treating equipment, and thermal processing systems due to their stability at high temperatures. In petrochemical and chemical plants, these fittings are used in piping systems handling corrosive media and high-temperature gases. They are also essential in power generation units, including gas turbines and exhaust systems, where strength and oxidation resistance are critical. Additionally, Inconel 601 fittings are utilized in aerospace, marine engineering, and pollution control equipment, ensuring reliable performance in demanding and corrosive environments.
