Yousef Metals stands out as a trusted manufacturer and supplier of Inconel Forged Fittings right in the heart of Doha, Qatar. They cater to industries that require top-notch strength and remarkable corrosion resistance. With state-of-the-art forging facilities and a commitment to quality control, this company produces fittings that align with international performance and durability standards. Yousef Metals prides itself on precision engineering, tailored solutions, and prompt delivery, supporting vital sectors like oil & gas, petrochemical, power generation, and marine projects throughout Qatar and the broader Middle East.
Inconel Forged Fittings are crafted from nickel-chromium-based superalloys, often enhanced with elements like molybdenum, iron, and niobium. This carefully controlled chemical makeup ensures excellent resistance to oxidation, corrosion, and high-temperature conditions. On the mechanical side, these fittings boast high tensile strength, exceptional toughness, and impressive creep resistance. They can handle extreme pressure and thermal stress without compromising their structural integrity. Plus, proper heat treatment boosts their hardness, fatigue resistance, and long-term reliability.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Inconel Forged Fittings from Yousef Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Yousef Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Yousef Metals, one of the leading suppliers of Inconel Forged Fittings in Doha, Qatar, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Yousef Metals has established itself as a trusted name for premium stainless steel products across the Qatar.
Yes, we provide custom sizes of Inconel Forged Fittings to match your exact project requirements. At Yousef Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@yousefmetals.com.
These Inconel Forged Fittings are a go-to choice for high-temperature and corrosive service applications. You’ll find them commonly used in oil and gas processing units, chemical plants, power stations, heat exchangers, and offshore platforms. They excel at managing aggressive chemicals, high-pressure fluids, and intense heat conditions. With their durability, strength, and resistance to environmental damage, these fittings ensure safe, efficient, and long-lasting performance in critical industrial piping systems.
