Yousef Metals is a reliable manufacturer and supplier of top-notch Reducing Outlet Tees based in Doha, Qatar. We cater to various industries, including oil & gas, petrochemical, power, and construction. Renowned for our precision engineering and rigorous quality control, we provide durable and corrosion-resistant outlet tees that comply with international standards like ASME, ASTM, and MSS. Our Reducing Outlet Tees are expertly designed to create dependable branch connections with reduced outlet diameters, ensuring efficient fluid flow management. With state-of-the-art manufacturing facilities, competitive pricing, and prompt delivery, Yousef Metals is committed to offering reliable piping solutions that meet the demanding industrial needs of Qatar and the broader Middle East region.
Typically, our Reducing Outlet Tees are crafted from materials such as carbon steel, stainless steel, alloy steel, or duplex steel, tailored to various service conditions. We use common material grades like ASTM A105, A106, A234 WPB, and A182, which provide exceptional strength, toughness, and resistance to corrosion. These fittings boast high tensile and yield strength, good ductility, and dependable impact resistance. Their mechanical properties enable them to endure high pressure, temperature fluctuations, and mechanical stress. Additionally, heat treatment and precise machining further boost their durability and performance in challenging industrial settings.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size: 1/2″ to 36″
Form: Butt weld Reducing Tee and Crosses, Fitting Outlet Reducing Tee and Crosses
Reducing Outlet Tees are commonly made from materials such as stainless steel, carbon steel, and various alloys, including Duplex and Super Duplex, depending on the application’s specific requirements. These materials offer excellent corrosion resistance, strength, and durability. The mechanical properties vary with the material used but generally include high tensile strength (500-900 MPa), yield strength (250-700 MPa), and elongation (20-30%). Reducing Outlet Tees are designed to withstand high-pressure, high-temperature environments, providing reliable performance in fluid and gas transmission system
| Nominal Pipe Size (NPS) | DN | Outlet Diameter at Bevel | Center- to-End | ||
| Run | Outlet | Run.C | Outlet. M[Notes(1)] | ||
| 1/2*1/2*3/8 | 15*15*10 | 21.3 | 17.3 | 25 | 25 |
| 1/2*1/2*1/4 | 15*15*8 | 21.3 | 13.7 | 25 | 25 |
| 3/4*3/4*1/2 | 20*20*15 | 26.7 | 21.3 | 29 | 29 |
| 3/4*3/4*3/8 | 20*20*10 | 26.7 | 17.3 | 29 | 29 |
| 1*1*3/4 | 25*25*20 | 33.4 | 26.7 | 38 | 38 |
| 1*1*1/2 | 25*25*15 | 33.4 | 21.3 | 38 | 38 |
| 1-1/4*1-1/4*1 | 32*32*25 | 42.2 | 33.4 | 48 | 48 |
| 1-1/4*1-1/4*3/4 | 32*32*20 | 42.2 | 26.7 | 48 | 48 |
| 1-1/4*1-1/4*1/2 | 32*32*15 | 42.2 | 21.3 | 48 | 48 |
| 1-1/2*1-1/2*1-1/4 | 40*40*32 | 48.3 | 42.2 | 57 | 57 |
| 1-1/2*1-1/2*1 | 40*40*25 | 48.3 | 33.4 | 57 | 57 |
| 1-1/2*1-1/2*3/4 | 40*40*20 | 48.3 | 26.7 | 57 | 57 |
| 1-1/2*1-1/2*1/2 | 40*40*15 | 48.3 | 21.3 | 57 | 57 |
| 2*2*1-1/2 | 50*50*40 | 60.3 | 48.3 | 64 | 60 |
| 2*2*1-1/4 | 50*50*32 | 60.3 | 42.2 | 64 | 57 |
| 2*2*1 | 50*50*25 | 60.3 | 33.4 | 64 | 51 |
| 2*2*3/4 | 50*50*20 | 60.3 | 73.0 | 64 | 44 |
| 2-1/2*2-1/2*2 | 65*65*50 | 73.0 | 60.3 | 76 | 70 |
| 2-1/2*2-1/2*1-1/2 | 65*65*40 | 73.0 | 48.3 | 76 | 67 |
| 2-1/2*2-1/2*1-1/4 | 65*65*32 | 73.0 | 42.2 | 76 | 64 |
| 2-1/2*2-1/2*1 | 65*65*25 | 73.0 | 88.9 | 76 | 57 |
| 3*3*2-1/2 | 80*80*65 | 88.9 | 73.0 | 86 | 83 |
| 3*3*2 | 80*80*50 | 88.9 | 60.3 | 86 | 76 |
| 3*3*1-1/2 | 80*80*40 | 88.9 | 48.3 | 86 | 73 |
| 3*3*1-1/4 | 80*80*32 | 88.9 | 101.6 | 86 | 70 |
| 3-1/2*3-1/2*3 | 90*90*80 | 101.6 | 88.9 | 95 | 92 |
| 3-1/2*3-1/2*2-1/2 | 90*90*65 | 101.6 | 73.0 | 95 | 89 |
| 3-1/2*3-1/2*2 | 90*90*50 | 101.6 | 60.3 | 95 | 83 |
| 3-1/2*3-1/2*1-1/2 | 90*90*40 | 101.6 | 48.3 | 95 | 79 |
| 4*4*3-1/2 | 100*100*90 | 114.3 | 101.6 | 105 | 102 |
| 4*4*3 | 100*100*80 | 114.3 | 88.9 | 105 | 98 |
| 4*4*2-1/2 | 100*100*65 | 114.3 | 73.0 | 105 | 95 |
| 4*4*2 | 100*100*50 | 114.3 | 60.3 | 105 | 89 |
| 4*4*1-1/2 | 100*100*40 | 114.3 | 48.3 | 105 | 86 |
| 5*5*4 | 125*125*100 | 141.3 | 114.3 | 124 | 117 |
| 5*5*3-1/2 | 125*125*90 | 141.3 | 101.6 | 124 | 114 |
| 5*5*3 | 125*125*80 | 141.3 | 88.9 | 124 | 111 |
| 5*5*2-1/2 | 125*125*65 | 141.3 | 73.6 | 124 | 108 |
| 5*5*2 | 125*125*50 | 141.3 | 60.3 | 124 | 105 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Reducing Outlet Tees from Yousef Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Yousef Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Yousef Metals, one of the leading suppliers of Reducing Outlet Tees in Doha, Qatar, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Yousef Metals has established itself as a trusted name for premium stainless steel products across the Qatar.
Yes, we provide custom sizes of Reducing Outlet Tees to match your exact project requirements. At Yousef Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@yousefmetals.com.
Reducing Outlet Tees are essential in piping systems where a smaller branch connection is needed from a main pipeline. They play a crucial role in oil and gas pipelines, petrochemical plants, power stations, desalination units, and industrial processing facilities. These fittings ensure efficient flow distribution while maintaining pressure integrity and system reliability. In Qatar’s energy and infrastructure sectors, Reducing Outlet Tees facilitate fluid transfer, steam lines, and chemical processing operations. Their compact design, leak-proof performance, and extended service life make them perfect for high-pressure and high-temperature applications.
